Name

Unit

Specification

Note

Process Range

（X/Y/Z）Three axis travel distance

mm

850/540/520

Distance from spindle center line to column guide surface

mm

570

Distance from spindle nose to work bench surface

mm

125~645

Work Bench

Work bench size

mm

1000×500

 MAX Load

kg

550

T-slot (slot number × slot width × spacing)

5×18×100

Spindle

 Spindle Speed

rpm

10000

 Spindle Taper

BT40

 Spindle Motor Power

kW

7.5/11

Speed

Rapid Moving (X/Y/Z)

m/min

48/48/48

 Rapid Feeding Speed

m/min

10/10/10

Tool Magazine

 Tool Magazine Number

 units

24

Tool MAX Diameter/length/weight

Æ75mm/300mm/7kg

Tool MAX Diameter (Full/Empty)

mm

75/150

Tool selection method

Any/order selection

Tool Changing time (from one tool to another)

S

1.8

Machine Accuracy

（X/Y/Z）Positioning Accuracy

mm

0.008

（X/Y/Z）Re-Positioning Accuracy

mm

0.005

Others

Air source/Air pressure

280L/min  6~8bar

Total electrical capacity of the machine

KVA

20

Water tank capacity

L

400

Machine size（X×Y×Z）

mm

2400×2650×2600

 Machine weight

kg

4900

No

Name

Quantity

Note

1

Mitsubishi M80B CNC system

1

2

Handheld operating unit

1

3

Disc Tool Magazine

1

24 units

4

Automatic lubrication system

1

5

LED Warning Light

1

6

Spindle blowing device

1

7

Air curtain protection

1

8

flashlight

1

9

Attached accessories

1

10

Attached Technical agreement

1
