HMC-2516NC Horizontal rough milling machining center
ES-TOP CNC Horizontal Machining Center HMC-2516NC
Machine Standard Specification
|
Model: HMC-2516NC |
Unit |
Specification |
|
|
Process Range |
Three axis travel |
mm |
2500/1600/550 |
|
Spindle center to column guide |
mm |
0-1600 |
|
|
Cutting Capacity |
cm³/min |
800 |
|
|
Worktable |
Worktable Size |
mm |
2500*1400 |
|
MAX Loading weight |
kg |
12000 |
|
|
Spindle |
Spindle Speed |
rpm |
0-3000rpm |
|
Spindle Taper |
- |
BT50-φ220 |
|
|
Spindle Motor |
KW |
30 |
|
|
Speed
|
Rapid Feeding (X/Y/Z) |
m/min |
6/6/6 |
|
Rapid Cutting Feeding (X/Y/Z) |
m/min |
5/5/5 |
|
|
Machine Accuracy |
Positioning |
mm |
0.02 |
|
Re-Positioning |
mm |
0.015 |
|
|
Lubricating Oil Tank |
L |
4 |
|
|
Machine size |
mm |
7500×4800x4300 |
|
|
Machine weight |
kg |
32000 |
|
|
System |
Mitsubishi M80 |
- |
- |
Machine Main configuration & Price
|
NO. |
MODEL |
DESCRIPTION |
AMOUNT |
|
1 |
HMC-2516NC |
One unit Horizontal Machining Center Controller Mitsubishi System
|
|
Machine Main configuration
|
No. |
Motor standard spec |
pcs |
|
1
|
Handheld operating unit |
1 |
|
2 |
Automatic lubrication system |
1 |
|
3 |
LED Warning Light |
1 |
|
4 |
Spindle blowing device |
1 |
|
5 |
Air curtain protection |
1 |
|
6 |
flashlight |
1 |
|
7 |
Attached accessories |
1 |
|
8 |
Attached Technical agreement |
1 |
