VM-2360NC CNC Precision Vertical Milling machine
I. Achieve the main function
CNC system once setting and automatic guides where work-piece loading place, automatic measurement, automatic process from rough machining to finishing machining, which can reduce working strength of operator and increase Productivity, maintain high accuracy for dimension, squareness and parallelism.
II. Product image and main technical parameters
|
VM-2360NC Specifications |
|||
|
No. |
ITEM |
Description |
Parameter |
|
1 |
Model |
CNC gantry milling machine |
VM-2360NC |
|
2 |
Vertical milling capacity |
Maximum machining length mm |
6000 |
|
|
|
Maximum machining width mm |
2300 |
|
|
|
Maximum processing height mm |
600 |
|
|
Sides milling capacity |
Maximum machining length mm |
5800 |
|
|
|
Maximum machining width mm |
2300 |
|
|
|
Maximum processing height mm |
450 |
|
3 |
Worktable |
Worktable size mm |
1800*6000 |
|
|
|
Max loading weight |
15000 |
|
4 |
Gear type Vertical milling head |
Spindle power kw |
15 |
|
|
|
Spindle taper |
BT50(7：24) |
|
|
|
Speed of mainshaft C/S |
50-500 |
|
|
|
Cutting diameter mm |
250 |
|
5 |
Gear type side Milling head (Manual) |
Spindle speed rpm |
75/115/165/240/345/505 |
|
|
|
Spindle power KW |
15 |
|
|
|
Cutting diameter mm |
250 |
|
|
|
Spindle taper |
BT50(7：24) |
|
6 |
Z-Axis Balance |
Nitrogen counterweight Balance system |
4 pcs |
|
7 |
Travelling speed |
X axis moving speed of mm/min |
0-6000 |
|
|
|
Y axis moving speed of mm/min |
0-8000 |
|
|
|
Z axis moving speed of mm/min |
0-8000 |
|
8 |
Motor power |
X,Y,Z axis motor KW |
7.5,3,3 |
|
9 |
Cover |
Metal sheep protect, open top, house cover, CE STADNARD |
House cover |
|
10 |
Dimension |
Inside width |
2300 |
|
|
|
Machine area mm |
14000*5000*4000 |
|
|
|
Machine weight Kg |
48000 |
