Double Column Type Surface Grinding machine ETLD-1625NC

ETLD-1625NC Estop Gantry Grinding Machine Gantry Grinding Machine

Main item	Double Column Type Surface Grinding machine	Unit	ETLD-160250
Worktable	Electromagnet table size(x*y)	mm	2500x1600
	Left and right Xaxis travel		2700
	Max center of wheel to table	mm	630
	Two column passed maximum workpiece size	mm	1930
	Worktable Maximum loading copacity	kg	6000
	Worktable feed speed	m/min	5-30
	Table t-slot specification	mm*n	18x6
Grinding wheel	Grinding wheel size max	mm	500x 203x50-75
	Spindle motor	HP*P	25x4
	（50HZ/60HZ) Grinding wheel speed	R.P.M	1450
Size	Height of machine（Move to top Height)	mm	≈3500
	Layout Floor space（Length X width）	mm	6750x3700
	Weight	kg	≈24000
