PCS-1000NC Specifications

No.

Item

Description

Specification

1

Machine

CNC sawing machine

PCS-1000NC

2

Cutting capacity

Control axis number

2

Cutting thickness mm

20-100

Cutting width mm

380-1000

Cutting length mm

140-1000

Automatic feeding length mm

4000 (It can be cycled multiple times)

3

Spindle

Spindle speed(Infinitely variable speeds) rpm

50-250

Spindle power KW

11/15

Saw blade diameter mm

500

4

X axis

Z axis

X/Z axis motor power KW

4.5/3.7

X/Z automatic feed speed mm/min

100-350

X/Z fast moving mm/min

6.5m/min

5

Accuracy

 Parallelism mm

≤0.15

Accuracy for dimension mm/300mm

±0.1

6

Tank capacity

Hydraulic oil tank L

30

Lubrication oil tank L

3

7

Power

Power

380V/220V 25kw

8

Weight and dimensions

Machine net weight T

13

Machine area mm

6000*3500*2200

9

Others

Cooling system

Water cooling

 Air Pressure

0.6Mpa

 Auto Run Method

Single/multiple

10

Conveyor

Conveyor length mm

3000

11

Movable bed

Max loading capacity KG

3500

PCS-1000NC  Main parts

Sort

Item

Quantity

    Original

Remark

Machine parts

Ball screw

2

Taiwan

steady transmission,High accuracy, wear-proof

guide rail

2

Taiwan

Strong stability

Main Spindle

1

ES-TOP

Low noise, high strength, Taiwan famous brand

Organ

2

Domestic

High strength, Strong durability, dust-proof, Protect the guide rail and ball screw.

Base casting

1

HT300

Good stability, excellent wear-ability

Automatic Lub oil unit

1

Domestic

Electronic-self-lubrication, Quantitative oil supply to the each part

Oil line

2

Domestic

Aluminium tube

Bearing

Taiwan TPI

Taiwan famous brand, High accuracy, High quality

Electrical

CNC system

1

Taiwan JK

High accuracy Top brand of CNC High accuracy

Servo motor

2

Taiwan TK

High accuracy Top brand of CNC High accuracy

Spindle  motor

1

MK/CTB

Multitronic, Meet the requirements of different processing speed

AC contactor

1

French Schneider

Famous brand, steady property

Relay

1

French Schneider

Famous brand, steady property
